import gym

env_name = "CartPole-v0"
env = gym.make(env_name)          # 导入环境

episodes = 10
for episode in range(1, episodes + 1):
    state = env.reset()
    done = False
    score = 0

    while not done:
        env.render()                           # 渲染环境
        action = env.action_space.sample()     # 随机采样动作
        n_state, reward, done, info = env.step(action)    # 和环境交互，得到下一个状态，奖励等信息
        score += reward                        # 计算分数
    print("Episode : {}, Score : {}".format(episode, score))

env.close()     # 关闭窗口

from stable_baselines3 import DQN
from stable_baselines3.common.vec_env.dummy_vec_env import DummyVecEnv
from stable_baselines3.common.evaluation import evaluate_policy
import gym

env_name = "CartPole-v0"
env = gym.make(env_name)
# 把环境向量化，如果有多个环境写成列表传入DummyVecEnv中，可以用一个线程来执行多个环境，提高训练效率
env = DummyVecEnv([lambda : env])
# 定义一个DQN模型，设置其中的各个参数
model = DQN(
    "MlpPolicy",                                # MlpPolicy定义策略网络为MLP网络
    env=env,
    learning_rate=5e-4,
    batch_size=128,
    buffer_size=50000,
    learning_starts=0,
    target_update_interval=250,
    policy_kwargs={"net_arch" : [256, 256]},     # 这里代表隐藏层为2层256个节点数的网络
    verbose=1,                                   # verbose=1代表打印训练信息，如果是0为不打印，2为打印调试信息
    tensorboard_log="./tensorboard/CartPole-v0/"  # 训练数据保存目录，可以用tensorboard查看
)
# 开始训练
model.learn(total_timesteps=1e5)
# 策略评估，可以看到倒立摆在平稳运行了
mean_reward, std_reward = evaluate_policy(model, env, n_eval_episodes=10, render=true)
#env.close()
print("mean_reward:",mean_reward,"std_reward:",std_reward)
# 保存模型到相应的目录
model.save("./model/CartPole.pkl")

import gym
from gym import spaces

class CustomEnv(gym.Env):
    """Custom Environment that follows gym interface"""
    metadata = {'render.modes': ['human']}

    def __init__(self, arg1, arg2, ...):
        super(CustomEnv, self).__init__()
        # Define action and observation space
        # They must be gym.spaces objects
        # Example when using discrete actions:
        self.action_space = spaces.Discrete(N_DISCRETE_ACTIONS)
        # Example for using image as input (channel-first; channel-last also works):
        self.observation_space = spaces.Box(low=0, high=255,
                                            shape=(N_CHANNELS, HEIGHT, WIDTH), dtype=np.uint8)

    def step(self, action):
        ...
        return observation, reward, done, info
    def reset(self):
        ...
        return observation  # reward, done, info can't be included
    def render(self, mode='human'):
        ...
    def close (self):
        pass

def test_make_data_loader():
    """Tests data loader produces same results for same input in different formats."""
    trajs = [
        types.Trajectory(
            obs=np.array([0, 1]),
            acts=np.array([100]),
            infos=None,
            terminal=True,
        ),
        types.Trajectory(
            obs=np.array([4, 5, 6]),
            acts=np.array([102, 103]),
            infos=None,
            terminal=True,
        ),
        types.Trajectory(
            obs=np.array([10, 11, 12, 13]),
            acts=np.array([104, 105, 106]),
            infos=None,
            terminal=False,
        ),
    ]
    trans = types.Transitions(
        obs=np.array([0, 4, 5, 10, 11, 12]),
        acts=np.array([100, 102, 103, 104, 105, 106]),
        next_obs=np.array([1, 5, 6, 11, 12, 13]),
        dones=np.array([True, False, True, False, False, False]),
        infos=np.array([{}] * 6),
    )
    trans_mapping = [
        {
            "obs": np.array([0, 4]),
            "acts": np.array([100, 102]),
            "next_obs": np.array([1, 5]),
            "dones": np.array([True, False]),
            "infos": np.array([{}, {}]),
        },
        {
            "obs": np.array([5, 10]),
            "acts": np.array([103, 104]),
            "next_obs": np.array([6, 11]),
            "dones": np.array([True, False]),
            "infos": np.array([{}, {}]),
        },
        {
            "obs": np.array([11, 12]),
            "acts": np.array([105, 106]),
            "next_obs": np.array([12, 13]),
            "dones": np.array([False]),
            "infos": np.array([{}, {}]),
        },
    ]

    for data in [trajs, trans, trans_mapping]:
        data_loader = base.make_data_loader(
            data,
            batch_size=2,
            data_loader_kwargs=dict(shuffle=False, drop_last=False),
        )
        for batch, expected_batch in zip(data_loader, trans_mapping):
            assert batch.keys() == expected_batch.keys()
            for k in batch.keys():
                v = batch[k]
                if isinstance(v, th.Tensor):
                    v = v.numpy()
                assert np.all(v == expected_batch[k])

from a2c_ppo_acktr.algo import gail

import copy
import glob
import os
import time
from collections import deque

import gym
import numpy as np
import torch
import torch.nn as nn
import torch.nn.functional as F
import torch.optim as optim

from a2c_ppo_acktr import algo, utils
from a2c_ppo_acktr.algo import gail
from a2c_ppo_acktr.arguments import get_args
from a2c_ppo_acktr.envs import make_vec_envs
from a2c_ppo_acktr.model import Policy
from a2c_ppo_acktr.storage import RolloutStorage
from evaluation import evaluate


def main():
    args = get_args()

    torch.manual_seed(args.seed)
    torch.cuda.manual_seed_all(args.seed)

    if args.cuda and torch.cuda.is_available() and args.cuda_deterministic:
        torch.backends.cudnn.benchmark = False
        torch.backends.cudnn.deterministic = True

    log_dir = os.path.expanduser(args.log_dir)
    eval_log_dir = log_dir + "_eval"
    utils.cleanup_log_dir(log_dir)
    utils.cleanup_log_dir(eval_log_dir)

    torch.set_num_threads(1)
    device = torch.device("cuda:0" if args.cuda else "cpu")

    envs = make_vec_envs(args.env_name, args.seed, args.num_processes,
                         args.gamma, args.log_dir, device, False)

    actor_critic = Policy(
        envs.observation_space.shape,
        envs.action_space,
        base_kwargs={'recurrent': args.recurrent_policy})
    actor_critic.to(device)

    if args.algo == 'a2c':
        agent = algo.A2C_ACKTR(
            actor_critic,
            args.value_loss_coef,
            args.entropy_coef,
            lr=args.lr,
            eps=args.eps,
            alpha=args.alpha,
            max_grad_norm=args.max_grad_norm)
    elif args.algo == 'ppo':
        agent = algo.PPO(
            actor_critic,
            args.clip_param,
            args.ppo_epoch,
            args.num_mini_batch,
            args.value_loss_coef,
            args.entropy_coef,
            lr=args.lr,
            eps=args.eps,
            max_grad_norm=args.max_grad_norm)
    elif args.algo == 'acktr':
        agent = algo.A2C_ACKTR(
            actor_critic, args.value_loss_coef, args.entropy_coef, acktr=True)

    if args.gail:
        assert len(envs.observation_space.shape) == 1
        discr = gail.Discriminator(
            envs.observation_space.shape[0] + envs.action_space.shape[0], 100,
            device)
        file_name = os.path.join(
            args.gail_experts_dir, "trajs_{}.pt".format(
                args.env_name.split('-')[0].lower()))

        expert_dataset = gail.ExpertDataset(
            file_name, num_trajectories=4, subsample_frequency=20)
        drop_last = len(expert_dataset) > args.gail_batch_size
        gail_train_loader = torch.utils.data.DataLoader(
            dataset=expert_dataset,
            batch_size=args.gail_batch_size,
            shuffle=True,
            drop_last=drop_last)

    rollouts = RolloutStorage(args.num_steps, args.num_processes,
                              envs.observation_space.shape, envs.action_space,
                              actor_critic.recurrent_hidden_state_size)

    obs = envs.reset()
    rollouts.obs[0].copy_(obs)
    rollouts.to(device)

    episode_rewards = deque(maxlen=10)

    start = time.time()
    num_updates = int(
        args.num_env_steps) // args.num_steps // args.num_processes
    for j in range(num_updates):

        if args.use_linear_lr_decay:
            # decrease learning rate linearly
            utils.update_linear_schedule(
                agent.optimizer, j, num_updates,
                agent.optimizer.lr if args.algo == "acktr" else args.lr)

        for step in range(args.num_steps):
            # Sample actions
            with torch.no_grad():
                value, action, action_log_prob, recurrent_hidden_states = actor_critic.act(
                    rollouts.obs[step], rollouts.recurrent_hidden_states[step],
                    rollouts.masks[step])

            # Obser reward and next obs
            obs, reward, done, infos = envs.step(action)

            for info in infos:
                if 'episode' in info.keys():
                    episode_rewards.append(info['episode']['r'])

            # If done then clean the history of observations.
            masks = torch.FloatTensor(
                [[0.0] if done_ else [1.0] for done_ in done])
            bad_masks = torch.FloatTensor(
                [[0.0] if 'bad_transition' in info.keys() else [1.0]
                 for info in infos])
            rollouts.insert(obs, recurrent_hidden_states, action,
                            action_log_prob, value, reward, masks, bad_masks)

        with torch.no_grad():
            next_value = actor_critic.get_value(
                rollouts.obs[-1], rollouts.recurrent_hidden_states[-1],
                rollouts.masks[-1]).detach()

        if args.gail:
            if j >= 10:
                envs.venv.eval()

            gail_epoch = args.gail_epoch
            if j < 10:
                gail_epoch = 100  # Warm up
            for _ in range(gail_epoch):
                discr.update(gail_train_loader, rollouts,
                             utils.get_vec_normalize(envs)._obfilt)

            for step in range(args.num_steps):
                rollouts.rewards[step] = discr.predict_reward(
                    rollouts.obs[step], rollouts.actions[step], args.gamma,
                    rollouts.masks[step])

        rollouts.compute_returns(next_value, args.use_gae, args.gamma,
                                 args.gae_lambda, args.use_proper_time_limits)

        value_loss, action_loss, dist_entropy = agent.update(rollouts)

        rollouts.after_update()

        # save for every interval-th episode or for the last epoch
        if (j % args.save_interval == 0
                or j == num_updates - 1) and args.save_dir != "":
            save_path = os.path.join(args.save_dir, args.algo)
            try:
                os.makedirs(save_path)
            except OSError:
                pass

            torch.save([
                actor_critic,
                getattr(utils.get_vec_normalize(envs), 'obs_rms', None)
            ], os.path.join(save_path, args.env_name + ".pt"))

        if j % args.log_interval == 0 and len(episode_rewards) > 1:
            total_num_steps = (j + 1) * args.num_processes * args.num_steps
            end = time.time()
            print(
                "Updates {}, num timesteps {}, FPS {} \n Last {} training episodes: mean/median reward {:.1f}/{:.1f}, min/max reward {:.1f}/{:.1f}\n"
                .format(j, total_num_steps,
                        int(total_num_steps / (end - start)),
                        len(episode_rewards), np.mean(episode_rewards),
                        np.median(episode_rewards), np.min(episode_rewards),
                        np.max(episode_rewards), dist_entropy, value_loss,
                        action_loss))

        if (args.eval_interval is not None and len(episode_rewards) > 1
                and j % args.eval_interval == 0):
            obs_rms = utils.get_vec_normalize(envs).obs_rms
            evaluate(actor_critic, obs_rms, args.env_name, args.seed,
                     args.num_processes, eval_log_dir, device)


if __name__ == "__main__":
    main()

import h5py
import numpy as np
import torch
import torch.nn as nn
import torch.nn.functional as F
import torch.utils.data
from torch import autograd

from stable_baselines3.common.running_mean_std import RunningMeanStd

class Discriminator(nn.Module):
    def __init__(self, input_dim, hidden_dim, device):
        super(Discriminator, self).__init__()

        self.device = device

        self.trunk = nn.Sequential(
            nn.Linear(input_dim, hidden_dim), nn.Tanh(),
            nn.Linear(hidden_dim, hidden_dim), nn.Tanh(),
            nn.Linear(hidden_dim, 1)).to(device)

        self.trunk.train()

        self.optimizer = torch.optim.Adam(self.trunk.parameters())

        self.returns = None
        self.ret_rms = RunningMeanStd(shape=())

    def compute_grad_pen(self,
                         expert_state,
                         expert_action,
                         policy_state,
                         policy_action,
                         lambda_=10):
        alpha = torch.rand(expert_state.size(0), 1)
        expert_data = torch.cat([expert_state, expert_action], dim=1)
        policy_data = torch.cat([policy_state, policy_action], dim=1)

        alpha = alpha.expand_as(expert_data).to(expert_data.device)

        mixup_data = alpha * expert_data + (1 - alpha) * policy_data
        mixup_data.requires_grad = True

        disc = self.trunk(mixup_data)
        ones = torch.ones(disc.size()).to(disc.device)
        grad = autograd.grad(
            outputs=disc,
            inputs=mixup_data,
            grad_outputs=ones,
            create_graph=True,
            retain_graph=True,
            only_inputs=True)[0]

        grad_pen = lambda_ * (grad.norm(2, dim=1) - 1).pow(2).mean()
        return grad_pen

    def update(self, expert_loader, rollouts, obsfilt=None):
        self.train()

        policy_data_generator = rollouts.feed_forward_generator(
            None, mini_batch_size=expert_loader.batch_size)

        loss = 0
        n = 0
        for expert_batch, policy_batch in zip(expert_loader,
                                              policy_data_generator):
            policy_state, policy_action = policy_batch[0], policy_batch[2]
            policy_d = self.trunk(
                torch.cat([policy_state, policy_action], dim=1))

            expert_state, expert_action = expert_batch
            expert_state = obsfilt(expert_state.numpy(), update=False)
            expert_state = torch.FloatTensor(expert_state).to(self.device)
            expert_action = expert_action.to(self.device)
            expert_d = self.trunk(
                torch.cat([expert_state, expert_action], dim=1))

            expert_loss = F.binary_cross_entropy_with_logits(
                expert_d,
                torch.ones(expert_d.size()).to(self.device))
            policy_loss = F.binary_cross_entropy_with_logits(
                policy_d,
                torch.zeros(policy_d.size()).to(self.device))

            gail_loss = expert_loss + policy_loss
            grad_pen = self.compute_grad_pen(expert_state, expert_action,
                                             policy_state, policy_action)

            loss += (gail_loss + grad_pen).item()
            n += 1

            self.optimizer.zero_grad()
            (gail_loss + grad_pen).backward()
            self.optimizer.step()
        return loss / n

    def predict_reward(self, state, action, gamma, masks, update_rms=True):
        with torch.no_grad():
            self.eval()
            d = self.trunk(torch.cat([state, action], dim=1))
            s = torch.sigmoid(d)
            reward = s.log() - (1 - s).log()
            if self.returns is None:
                self.returns = reward.clone()

            if update_rms:
                self.returns = self.returns * masks * gamma + reward
                self.ret_rms.update(self.returns.cpu().numpy())

            return reward / np.sqrt(self.ret_rms.var[0] + 1e-8)


class ExpertDataset(torch.utils.data.Dataset):
    def __init__(self, file_name, num_trajectories=4, subsample_frequency=20):
        all_trajectories = torch.load(file_name)

        perm = torch.randperm(all_trajectories['states'].size(0))
        idx = perm[:num_trajectories]

        self.trajectories = {}

        # See https://github.com/pytorch/pytorch/issues/14886
        # .long() for fixing bug in torch v0.4.1
        start_idx = torch.randint(
            0, subsample_frequency, size=(num_trajectories, )).long()

        for k, v in all_trajectories.items():
            data = v[idx]

            if k != 'lengths':
                samples = []
                for i in range(num_trajectories):
                    samples.append(data[i, start_idx[i]::subsample_frequency])
                self.trajectories[k] = torch.stack(samples)
            else:
                self.trajectories[k] = data // subsample_frequency

        self.i2traj_idx = {}
        self.i2i = {}

        self.length = self.trajectories['lengths'].sum().item()

        traj_idx = 0
        i = 0

        self.get_idx = []

        for j in range(self.length):

            while self.trajectories['lengths'][traj_idx].item() <= i:
                i -= self.trajectories['lengths'][traj_idx].item()
                traj_idx += 1

            self.get_idx.append((traj_idx, i))

            i += 1


    def __len__(self):
        return self.length

    def __getitem__(self, i):
        traj_idx, i = self.get_idx[i]

        return self.trajectories['states'][traj_idx][i], self.trajectories[
            'actions'][traj_idx][i]

import numpy as np
import gym
from stable_baselines3 import PPO
from stable_baselines3.common.evaluation import evaluate_policy
from stable_baselines3.common.vec_env import DummyVecEnv
from stable_baselines3.ppo import MlpPolicy

from imitation.algorithms.adversarial.gail import GAIL
from imitation.data import rollout
from imitation.data.wrappers import RolloutInfoWrapper
from imitation.rewards.reward_nets import BasicRewardNet
from imitation.util.networks import RunningNorm
from imitation.util.util import make_vec_env

rng = np.random.default_rng(0)

env = gym.make("seals/CartPole-v0")
expert = PPO(policy=MlpPolicy, env=env, n_steps=64)
expert.learn(1000)

rollouts = rollout.rollout(
    expert,
    make_vec_env(
        "seals/CartPole-v0",
        n_envs=5,
        post_wrappers=[lambda env, _: RolloutInfoWrapper(env)],
        rng=rng,
    ),
    rollout.make_sample_until(min_timesteps=None, min_episodes=60),
    rng=rng,
)

venv = make_vec_env("seals/CartPole-v0", n_envs=8, rng=rng)
learner = PPO(env=venv, policy=MlpPolicy)
reward_net = BasicRewardNet(
    venv.observation_space,
    venv.action_space,
    normalize_input_layer=RunningNorm,
)
gail_trainer = GAIL(
    demonstrations=rollouts,
    demo_batch_size=1024,
    gen_replay_buffer_capacity=2048,
    n_disc_updates_per_round=4,
    venv=venv,
    gen_algo=learner,
    reward_net=reward_net,
)

gail_trainer.train(20000)
rewards, _ = evaluate_policy(learner, venv, 100, return_episode_rewards=True)
print("Rewards:", rewards)

import argparse
import gym
import numpy as np
import tensorflow as tf
from network_models.policy_net import Policy_net
from network_models.discriminator import Discriminator
from algo.ppo import PPOTrain

def argparser():
    parser = argparse.ArgumentParser()
    parser.add_argument('--logdir', help='log directory', default='log/train/gail')
    parser.add_argument('--savedir', help='save directory', default='trained_models/gail')
    parser.add_argument('--gamma', default=0.95)
    parser.add_argument('--iteration', default=int(1e4))
    return parser.parse_args()


def main(args):
    env = gym.make('CartPole-v0')
    env.seed(0)
    ob_space = env.observation_space
    Policy = Policy_net('policy', env)
    Old_Policy = Policy_net('old_policy', env)
    PPO = PPOTrain(Policy, Old_Policy, gamma=args.gamma)
    D = Discriminator(env)

    # 得到专家的观测和行动
    expert_observations = np.genfromtxt('trajectory/observations.csv')
    expert_actions = np.genfromtxt('trajectory/actions.csv', dtype=np.int32)

    saver = tf.train.Saver()

    with tf.Session() as sess:
        writer = tf.summary.FileWriter(args.logdir, sess.graph)
        sess.run(tf.global_variables_initializer())

        obs = env.reset()
        success_num = 0

        for iteration in range(args.iteration):
            observations = []
            actions = []
            rewards = []
            v_preds = []
            run_policy_steps = 0

            while True:
                run_policy_steps += 1
                obs = np.stack([obs]).astype(dtype=np.float32)
                act, v_pred = Policy.act(obs = obs,stochastic = True)

                act = np.asscalar(act)
                v_pred = np.asscalar(v_pred)

                next_obs,reward,done,info = env.step(act)

                observations.append(obs)
                actions.append(act)
                rewards.append(reward)
                v_preds.append(v_pred)

                if done:
                    next_obs = np.stack([next_obs]).astype(dtype=np.float32)  # prepare to feed placeholder Policy.obs
                    _, v_pred = Policy.act(obs=next_obs, stochastic=True)
                    v_preds_next = v_preds[1:] + [np.asscalar(v_pred)]
                    obs = env.reset()
                    break
                else:
                    obs = next_obs

            writer.add_summary(tf.Summary(value=[tf.Summary.Value(tag='episode_length', simple_value=run_policy_steps)])
                               , iteration)
            writer.add_summary(tf.Summary(value=[tf.Summary.Value(tag='episode_reward', simple_value=sum(rewards))])
                               , iteration)

            if sum(rewards) >= 195:
                success_num += 1
                if success_num >= 100:
                    saver.save(sess, args.savedir + '/model.ckpt')
                    print('Clear!! Model saved.')
                    break
            else:
                success_num = 0

            observations = np.reshape(observations,newshape=[-1] + list(ob_space.shape))
            actions = np.array(actions).astype(dtype = np.int32)

            for i in range(2):
                D.train(expert_s = expert_observations,
                        expert_a = expert_actions,
                        agent_s = observations,
                        agent_a = actions)


            d_rewards = D.get_rewards(agent_s=observations,agent_a = actions)
            d_rewards = np.reshape(d_rewards,newshape=[-1]).astype(dtype=np.float32)

            gaes = PPO.get_gaes(rewards=d_rewards, v_preds=v_preds, v_preds_next=v_preds_next)
            gaes = np.array(gaes).astype(dtype=np.float32)
            # gaes = (gaes - gaes.mean()) / gaes.std()
            v_preds_next = np.array(v_preds_next).astype(dtype=np.float32)

            # train policy
            inp = [observations, actions, gaes, d_rewards, v_preds_next]
            PPO.assign_policy_parameters()
            for epoch in range(6):
                sample_indices = np.random.randint(low=0, high=observations.shape[0],
                                                   size=32)  # indices are in [low, high)
                sampled_inp = [np.take(a=a, indices=sample_indices, axis=0) for a in inp]  # sample training data
                PPO.train(obs=sampled_inp[0],
                          actions=sampled_inp[1],
                          gaes=sampled_inp[2],
                          rewards=sampled_inp[3],
                          v_preds_next=sampled_inp[4])

            summary = PPO.get_summary(obs=inp[0],
                                      actions=inp[1],
                                      gaes=inp[2],
                                      rewards=inp[3],
                                      v_preds_next=inp[4])

            writer.add_summary(summary, iteration)
        writer.close()


if __name__ == '__main__':
    args = argparser()
    main(args)

import torch
from torch import nn
from torch.nn import init
import numpy as np
import sys
import torchvision
import torchvision.transforms as transforms
import time
import matplotlib.pyplot as plt
import os

os.environ["KMP_DUPLICATE_LIB_OK"]="TRUE"


# 导入FashionMNIST数据集
mnist_train = torchvision.datasets.FashionMNIST(root='~/Datasets/FashionMNIST', train=True, download=True, transform=transforms.ToTensor())
mnist_test = torchvision.datasets.FashionMNIST(root='~/Datasets/FashionMNIST', train=False, download=True, transform=transforms.ToTensor())


# 处理数据集，把数据转换成张量，使数据可以输入下面我们搭建的网络
def load_data_fashion_mnist(mnist_train, mnist_test, batch_size):
    if sys.platform.startswith('win'):
        num_workers = 0
    else:
        num_workers = 4
    train_data = torch.utils.data.DataLoader(mnist_train, batch_size=batch_size, shuffle=True, num_workers=num_workers)
    test_data = torch.utils.data.DataLoader(mnist_test, batch_size=batch_size, shuffle=False, num_workers=num_workers)
    return train_data, test_data


class LeNet(nn.Module):
    def __init__(self):
        super(LeNet, self).__init__()
        self.conv = nn.Sequential(
            nn.Conv2d(in_channels=1, out_channels=6, kernel_size=5), # in_channels, out_channels, kernel_size
            nn.LeakyReLU(0.1),
            nn.MaxPool2d(2, 2), # kernel_size, stride
            nn.Conv2d(6, 16, 5),
            nn.LeakyReLU(0.1),
            nn.MaxPool2d(2, 2)
        )
        self.fc = nn.Sequential(
            nn.Linear(16*4*4, 120),
            nn.LeakyReLU(0.1),
            nn.Linear(120, 84),
            nn.ReLU(),
            nn.Linear(84, 10)
        )

    def forward(self, img):
        feature = self.conv(img)
        output = self.fc(feature.view(img.shape[0], -1))
        return output

# 测试准确率计算
def evaluate_accuracy(data_iter, net, device=None):
    if device is None and isinstance(net, torch.nn.Module):
        # 如果没指定device就使用net的device
        device = list(net.parameters())[0].device
    acc_sum, n = 0.0, 0
    with torch.no_grad():
        for X, y in data_iter:
            net.eval()  # 评估模式, 这会关闭dropout
            acc_sum += (net(X.to(device)).argmax(dim=1) == y.to(device)).float().sum().cpu().item()
            net.train()  # 改回训练模式
            n += y.shape[0]
    return acc_sum / n


# 训练函数
def train(net, train_data, test_data, batch_size, optimizer, device, num_epochs):
    net = net.to(device)
    print("training on ", device)
    loss_function = torch.nn.CrossEntropyLoss()   # 定义损失函数（交叉熵损失函数）
    ax = []  # 保存等会更新的epoch，loss,train_acc,test_acc，用于绘制动态折线图
    ay1 = []
    ay2 = []
    ay3 = []
    plt.ion()
    # 开始训练
    for epoch in range(num_epochs):
        train_l_sum, train_acc_sum, n, batch_count, start = 0.0, 0.0, 0, 0, time.time()  # 初始化参数
        for X, y in train_data:
            X = X.to(device)      # 把参数导入GPU训练
            y = y.to(device)
            y_hat = net(X)
            l = loss_function(y_hat, y)   # 使用损失函数计算loss
            optimizer.zero_grad() # 把梯度置零，也就是把loss关于weight的导数变成0
            l.backward()   # 反向传播
            optimizer.step()
            train_l_sum += l.cpu().item()
            train_acc_sum += (y_hat.argmax(dim=1) == y).sum().cpu().item()
            n += y.shape[0]
            batch_count += 1
        test_acc = evaluate_accuracy(test_data, net)  # 测试当个epoch的训练的网络
        print('epoch %d, loss %.4f, train acc %.3f, test acc %.3f, time %.1f sec'
              % (epoch + 1, train_l_sum / batch_count, train_acc_sum / n, test_acc, time.time() - start))
        # 绘制动态折线图（如果不想绘制，可以删掉）
        plt.clf()  # 清除刷新前的图表，防止数据量过大消耗内存
        ax.append(epoch + 1)  # 追加x坐标值
        ay1.append(train_l_sum / batch_count)  # 追加y坐标值
        ay2.append(train_acc_sum / n)
        ay3.append(test_acc)
        plt.plot(ax, ay1, 'g-')
        plt.plot(ax, ay2, 'r-')
        plt.plot(ax, ay3, '-')
        plt.ylabel("epoch")
        plt.plot(ax, ay1, label="loss")  # 在绘图函数添加一个属性label
        plt.plot(ax, ay2, label="train_acc")
        plt.plot(ax, ay3, label="test_acc")
        plt.legend(loc=2)  # 添加图例，loc为图例位置，1为右上角，2为左上角，3为左下角，4为右下角
        plt.grid()   # 添加网格
        plt.pause(5)  # 设置暂停时间，太快图表无法正常显示
        plt.ioff()  # 关闭画图的窗口，即关闭交互模式
    plt.show()  # 显示图片，防止闪退


if __name__ == '__main__':
    batch_size = 256   # 批量数大小
    train_data, test_data = load_data_fashion_mnist(mnist_train, mnist_test, batch_size)
    device = torch.device('cuda' if torch.cuda.is_available() else 'cpu')  # 使用GPU,如果没有则使用CPU
    net = LeNet()    # 导入我们搭建好的网络
    lr, num_epochs = 0.001, 10
    optimizer = torch.optim.Adam(net.parameters(), lr=lr)  # 优化函数
    train(net, train_data, test_data, batch_size, optimizer, device, num_epochs)

class AlexNet(nn.Module):
    def __init__(self):
        super(AlexNet, self).__init__()
        self.conv = nn.Sequential(
            nn.Conv2d(1, 96, 11, 4), # in_channels, out_channels, kernel_size, stride, padding
            nn.ReLU(),
            nn.MaxPool2d(3, 2), # kernel_size, stride
            # 减小卷积窗口，使用填充为2来使得输入与输出的高和宽一致，且增大输出通道数
            nn.Conv2d(96, 256, 5, 1, 2),
            nn.ReLU(),
            nn.MaxPool2d(3, 2),
            # 连续3个卷积层，且使用更小的卷积窗口。除了最后的卷积层外，进一步增大了输出通道数。
            nn.Conv2d(256, 384, 3, 1, 1),
            nn.ReLU(),
            nn.Conv2d(384, 384, 3, 1, 1),
            nn.ReLU(),
            nn.Conv2d(384, 256, 3, 1, 1),
            nn.ReLU(),
            nn.MaxPool2d(3, 2)
        )
        self.fc = nn.Sequential(
            nn.Linear(256*5*5, 4096),
            nn.ReLU(),
            nn.Dropout(0.5),
            nn.Linear(4096, 4096),
            nn.ReLU(),
            nn.Dropout(0.5),
            nn.Linear(4096, 10),
        )

    def forward(self, img):
        feature = self.conv(img)
        output = self.fc(feature.view(img.shape[0], -1))
        return output

import time
import torch
from torch import nn, optim
import torchvision
import sys

device = torch.device('cuda' if torch.cuda.is_available() else 'cpu')

def load_data_fashion_mnist(batch_size, resize=None, root='~/Datasets/FashionMNIST'):
    if sys.platform.startswith('win'):
        num_workers = 0
    else:
        num_workers = 4
    trans = []
    if resize:
        trans.append(torchvision.transforms.Resize(size=resize))
    trans.append(torchvision.transforms.ToTensor())

    transform = torchvision.transforms.Compose(trans)
    mnist_train = torchvision.datasets.FashionMNIST(root=root, train=True, download=True, transform=transform)
    mnist_test = torchvision.datasets.FashionMNIST(root=root, train=False, download=True, transform=transform)

    train_iter = torch.utils.data.DataLoader(mnist_train, batch_size=batch_size, shuffle=True, num_workers=num_workers)
    test_iter = torch.utils.data.DataLoader(mnist_test, batch_size=batch_size, shuffle=False, num_workers=num_workers)

    return train_iter, test_iter

batch_size = 128
train_iter, test_iter = load_data_fashion_mnist(batch_size, resize=224)

class AlexNet(nn.Module):
    def __init__(self):
        super(AlexNet, self).__init__()
        self.conv = nn.Sequential(
            nn.Conv2d(1, 96, 11, 4), # in_channels, out_channels, kernel_size, stride, padding
            nn.ReLU(),
            nn.MaxPool2d(3, 2), # kernel_size, stride
            # 减小卷积窗口，使用填充为2来使得输入与输出的高和宽一致，且增大输出通道数
            nn.Conv2d(96, 256, 5, 1, 2),
            nn.ReLU(),
            nn.MaxPool2d(3, 2),
            # 连续3个卷积层，且使用更小的卷积窗口。除了最后的卷积层外，进一步增大了输出通道数。
            nn.Conv2d(256, 384, 3, 1, 1),
            nn.ReLU(),
            nn.Conv2d(384, 384, 3, 1, 1),
            nn.ReLU(),
            nn.Conv2d(384, 256, 3, 1, 1),
            nn.ReLU(),
            nn.MaxPool2d(3, 2)
        )
        self.fc = nn.Sequential(
            nn.Linear(256*5*5, 4096),
            nn.ReLU(),
            nn.Dropout(0.5),
            nn.Linear(4096, 4096),
            nn.ReLU(),
            nn.Dropout(0.5),
            nn.Linear(4096, 10),
        )

    def forward(self, img):
        feature = self.conv(img)
        output = self.fc(feature.view(img.shape[0], -1))
        return output

net = AlexNet()

def evaluate_accuracy(data_iter, net, device=None):
    if device is None and isinstance(net, torch.nn.Module):
        # 如果没指定device就使用net的device
        device = list(net.parameters())[0].device
    acc_sum, n = 0.0, 0
    with torch.no_grad():
        for X, y in data_iter:
            net.eval() # 评估模式, 这会关闭dropout
            acc_sum += (net(X.to(device)).argmax(dim=1) == y.to(device)).float().sum().cpu().item()
            net.train() # 改回训练模式
            n += y.shape[0]
    return acc_sum / n


def train(net, train_iter, test_iter, batch_size, optimizer, device, num_epochs):
    net = net.to(device)
    print("training on ", device)
    loss = torch.nn.CrossEntropyLoss()
    for epoch in range(num_epochs):
        train_l_sum, train_acc_sum, n, batch_count, start = 0.0, 0.0, 0, 0, time.time()
        for X, y in train_iter:
            X = X.to(device)
            y = y.to(device)
            y_hat = net(X)
            l = loss(y_hat, y)
            optimizer.zero_grad()
            l.backward()
            optimizer.step()
            train_l_sum += l.cpu().item()
            train_acc_sum += (y_hat.argmax(dim=1) == y).sum().cpu().item()
            n += y.shape[0]
            batch_count += 1
        test_acc = evaluate_accuracy(test_iter, net)
        print('epoch %d, loss %.4f, train acc %.3f, test acc %.3f, time %.1f sec'
              % (epoch + 1, train_l_sum / batch_count, train_acc_sum / n, test_acc, time.time() - start))

lr, num_epochs = 0.001, 5
optimizer = torch.optim.Adam(net.parameters(), lr=lr)
train(net, train_iter, test_iter, batch_size, optimizer, device, num_epochs)
